Chopping Machine

Size reduction of herbal medicine in ayurvedic pharmaceutical industry, food industry, wood industry, etc
Chopping Machine is widely used in ayurvedic pharmaceutical industry for shredding or size reduction of hard wooden dry herbs. The machine is in robust design and construction to suit large production plants and can be run continuously to meet high production demands. Special high-grade steel inter changeable beaters are used for better performance and long life.
Impact shearing with flexible beaters, customisable screen, high tensile steel hammers, full stainless steel or carbon steel body options.
Size reduction of herbal medicine in ayurvedic pharmaceutical industry, food industry, wood industry, etc
Model Capacity Motor Power Feed Material Size Output size
SM15 75-100Kg/Hr 7.5Hp 25mm x 250mm long Upto 4mm x 25mm
SM20 150-200 kg/Hr 10Hp 75mm x 400mm long Upto 6mm x 40mm
SM25 300-400 kg/Hr 20Hp 100mm x 700mm long Upto 6mm x 60mm

Similiar Product of Chopping Machine

Thermic Fluid Jacketed Pressure Vessel

Cylindrical type, double jacketed with separate isolation valves, easy operated hinged lid. Heating medium thermic fluid, perforated basket, safety features-pressure gauge, safety valve, pressure relief valve, positive closing valve, thermal insulation with stainless steel fully welded cladding.

Juice Extractor Medium Duty

High production capacity, high efficiency over input power, maximum liquid extraction, pressure adjusting cone, noise free operation, no hard foundation required, complete stainless steel construction, heavy duty gear, easy operation, etc.

Fruit Press – Hydraulic Heavy Duty

Manual DC valve operation, optional dual speed pressing. Contact parts stainless steel.

Chaff Cutter

Heavy duty construction, high tensile hardened blades, reversing arrangement, contact parts in stainless steel as optional.

Desintegrator

Impact shearing with fixed beaters, removable screen, high tensile steel hammers, stainless steel or carbon steel body painted dual layer hammer tone over metal primer.

Double Shaft Shredder

High resistant knives, high torque cutting shaft, large volume hopper, slow rpm with minimum vibration, long life knives, etc.
