Jacketed Dish Pan with Stirrer

Stainless steel Jacketed Dish pan is used for cooking various food preparations or making herbal preparations like oils, thailams, lehyam, ghee, etc. Indirect heating by steam or thermic fluid is used. Single or double jacket options are available. Motorised with gearbox, teflon lined stirrer fitted for stirring operation. Thermal insulation with mineral wool and stainless steel cladding is also provided around the vessel for protection from heat. Heat can be regulated according to requirement, resulting in saving of cost and for improvement in quality.
Heavy duty customisable stirrer with teflon liner, single shell joint free stainless steel deep dish, fitted on legs, single or double jacket, Thermal insulation with stainless steel fully welded cladding, full covered lid in stainless steel.
Ayurvedic pharmaceutical industry, food industry, beverage industry, etc.
ModelWorking CapacityDimensionsMotor
150L120Ltrs1000 Dia1Hp
250L220Ltrs1200mm2Hp
300L260Ltrs1200mm2Hp
500L400Ltrs1500mm3Hp
600L500Ltrs1500mm3Hp / 5Hp
700L600Ltrs1500mm5Hp
