Heavy Duty Electrical Tray Dryer

Dehydration and drying of vegetables, fruits, coconut, spices, herbal medicines, etc. Ayurvedic pharmaceutical industry, food industry, etc.
Heavy Duty Electric Tray Dryers are used to dry agro products like fruits, vegetables, coconut, spices and herbal medicines and tablets. Electric heaters are used as heating medium in the equipment. Recirculation blowers are used inside the dryer chamber for improved drying ability. Heating is controlled by control panel with electric thermostat. Tray dryers are made according to the size and capacity as required by the customer. Stainless steel trays are used for holding the material. Trays are kept in a fixed rack or movable trolleys for portability.
Robust construction, heavy wall slagwool insulation to minmize heat loss. Stainless steel cladding inside. Full control panel with thermostat and fan control. Metal recirculation fan with 3 phase motor for long life. Plain metal or perforated tray in stainless steel.
Dehydration and drying of vegetables, fruits, coconut, spices, herbal medicines, etc. Ayurvedic pharmaceutical industry, food industry, etc.
Model Capacity Heater Fan Motor
TD12-E 12Trays 4.5KW 1Hp x 1
TD24-E 24Trays 9.0KW 1Hp x 2
TD48-E 48Trays 16.0KW 1Hp x 2
