Jacketed Dish Pan with Stirrer LPG

Ayurvedic pharmaceutical industry, food industry, beverage industry, etc.
Jacketed Dish Pan with Stirrer- LPG is used for cooking various food preparations or making herbal preparations like oils, thailams, lehyam, ghee, etc. Outer jacket vessel is filled with thermic fluid and indirect heating done by multiple LPG high pressure burners fitted below the vessel. Single or double jacket options are available. Motorised with gearbox, teflon lined stirrer fitted for stirring operation. Vessel is fitted on A-type frame and can be tilted for material discharge. Thermal insulation with mineral wool and stainless steel cladding is also provided around the vessel for protection from heat.
Single shell joint free stainless steel deep dish, heavy duty customisable stirrer with teflon liner, fitted on A-type frame with tilting arrangement, single or double jacket, thermal insulation with stainless steel fully welded cladding, full covered lid in stainless steel.
Ayurvedic pharmaceutical industry, food industry, beverage industry, etc.
Model Working Capacity Dimensions Motor
150L 120Ltrs 1000 Dia 1Hp
250L 220Ltrs 1200mm 2Hp
300L 260Ltrs 1200mm 2Hp

Similiar Product of Jacketed Dish Pan with Stirrer LPG

Thermic Fluid Jacketed Pressure Vessel

Cylindrical type, double jacketed with separate isolation valves, easy operated hinged lid. Heating medium thermic fluid, perforated basket, safety features-pressure gauge, safety valve, pressure relief valve, positive closing valve, thermal insulation with stainless steel fully welded cladding.

Thermic Fluid Jacketed Cooking Vessel

Stainless steel vessel, LPG high pressure burner firing, tilting arrangement, ball valve discharge, medicine hanging hooks, safety features – safety valve and a positive closing valve. Frame in Stainless steel or Carbon steel.

Juice Extractor Medium Duty

High production capacity, high efficiency over input power, maximum liquid extraction, pressure adjusting cone, noise free operation, no hard foundation required, complete stainless steel construction, heavy duty gear, easy operation, etc.

Juice Extractor Small Scale

Maximum liquid extraction, pressure adjusting cone, noise free operation, no hard foundation required, complete stainless steel construction, easy operation.

Fruit Press – Hydraulic Compact

Manual DC valve operation, contact parts stainless steel.

Micro Pulverizer

Impact type high grade tip brazed shearing hammers, Water cooled grinding and classifier chamber, Dust colletion sylo. Output fineness 80 to 300 mesh. Complete stainless steel, Contact parts stainless steel and carbon steel versions are available. Cotton balloon Set.
